About Dear ImGui Bundle

Dear ImGui Bundle is a bundle for Dear ImGui, including various powerful libraries from its ecosystem. It enables to easily create ImGui applications in C++ and Python, under Windows, macOS, and Linux. It is aimed at application developers, researchers, and beginner developers who want to quickly get started.

Click here to see how easy a hello world can be:

In C++

#include "immapp/immapp.h"
#include "imgui.h"

void Gui()
    ImGui::Text("Hello, world!");

int main(int, char **)
        true // window_size_auto
        // Uncomment the next line to restore window position and size from previous run
        // , true // windowRestorePreviousGeometry

    return 0;


imgui_bundle_add_app(demo_hello_world demo_hello_world.cpp)

In Python

from imgui_bundle import imgui, immapp

def gui():
    imgui.text("Hello, world!")
    gui_function=gui,  # The Gui function to run
    window_title="Hello!",  # the window title
    window_size_auto=True,  # Auto size the application window given its widgets
    # Uncomment the next line to restore window position and size from previous run
    # window_restore_previous_geometry==True
The interactive manual provides lots of examples together with their source.

Interactive manual & demo in one click!

Click on the animated demonstration below to launch the fully interactive demonstration.

Figure 1. Dear ImGui Bundle interactive demo
This demonstration is also an interactive manual, similar to the online ImGui Manual

Batteries included

Dear ImGui Bundle includes the following libraries:

A big thank you to their authors for their awesome work!

Easily port your code between python and C++

The python bindings are autogenerated via an advanced generator (so that keeping them up to date is easy), and closely mirror the original C++ API, with fully typed bindings.

The original code documentation is meticulously kept inside the python stubs. See for example the documentation for imgui , implot, and hello imgui

Thanks to this, code completion in your favorite python IDE works like a charm, and porting code between Python and C++ becomes easy.

Click to see an example



import time
import numpy as np

from imgui_bundle import implot, imgui_knobs, imgui, immapp, hello_imgui

# Fill x and y whose plot is a heart
vals = np.arange(0, np.pi * 2, 0.01)
x = np.power(np.sin(vals), 3) * 16
y = 13 * np.cos(vals) - 5 * np.cos(2 * vals) - 2 * np.cos(3 * vals) - np.cos(4 * vals)
# Heart pulse rate and time tracking
phase = 0
t0 = time.time() + 0.2
heart_pulse_rate = 80

def gui():
    global heart_pulse_rate, phase, t0, x, y
    # Make sure that the animation is smooth
    hello_imgui.get_runner_params().fps_idling.enable_idling = False

    t = time.time()
    phase += (t - t0) * heart_pulse_rate / (np.pi * 2)
    k = 0.8 + 0.1 * np.cos(phase)
    t0 = t

    imgui.text("Bloat free code")
    implot.begin_plot("Heart", immapp.em_to_vec2(21, 21))
    implot.plot_line("", x * k, y * k)

    _, heart_pulse_rate = imgui_knobs.knob("Pulse", heart_pulse_rate, 30, 180)

if __name__ == "__main__":, window_size=(300, 450), window_title="Hello!", with_implot=True, fps_idle=0)  # type: ignore


#include "imgui.h"
#include "implot/implot.h"
#include "imgui-knobs/imgui-knobs.h"
#include "immapp/immapp.h"

#include <cmath>

std::vector<double> VectorTimesK(const std::vector<double>& values, double k)
    std::vector<double> r(values.size(), 0.);
    for (size_t i = 0; i < values.size(); ++i)
        r[i] = k * values[i];
    return r;

int main(int , char *[]) {
    // Fill x and y whose plot is a heart
    double pi = 3.1415926535;
    std::vector<double>  x, y; {
        for (double t = 0.; t < pi * 2.; t += 0.01) {
            x.push_back(pow(sin(t), 3.) * 16.);
            y.push_back(13. * cos(t) - 5 * cos(2. * t) - 2 * cos(3. * t) - cos(4. * t));
    // Heart pulse rate and time tracking
    double phase = 0., t0 = ImmApp::ClockSeconds() + 0.2;
    float heart_pulse_rate = 80.;

    auto gui = [&]() {
        // Make sure that the animation is smooth
        HelloImGui::GetRunnerParams()->fpsIdling.enableIdling = false;

        double t = ImmApp::ClockSeconds();
        phase += (t - t0) * (double)heart_pulse_rate / (pi * 2.);
        double k = 0.8 + 0.1 * cos(phase);
        t0 = t;

        ImGui::Text("Bloat free code");
        auto xk = VectorTimesK(x, k), yk = VectorTimesK(y, k);
        ImPlot::BeginPlot("Heart", ImmApp::EmToVec2(21, 21));
        ImPlot::PlotLine("",,, (int)xk.size());

        ImGuiKnobs::Knob("Pulse", &heart_pulse_rate, 30., 180.);

        gui, "Hello!",
        /*windowSizeAuto=*/false , /*windowRestorePreviousGeometry==*/false, /*windowSize=*/{300, 450},
        /*fpsIdle=*/ 25.f, /*withImplot=*/true);
    return 0;

Repository folders structure

Click to see a detailed explanation of this repository folder structure.
+-- -> bindings/imgui_bundle/           # doc
+-- _example_integration/                                   # Demonstrate how to easily use
|         +-- CMakeLists.txt                                # imgui_bundle in a C++ app
|         +-- assets/
|         +-- hello_world.main.cpp
+-- imgui_bundle_cmake/                                     # imgui_bundle_add_app() :
|         |                                                 # a cmake function you can use
|         +-- imgui_bundle_add_app.cmake                    # to create an app in one line
+-- bindings/                                               # root for the python bindings
|         +-- imgui_bundle/
|                  +-- assets/                              # assets/ folder: you need to
|                  |                                        # copy this folder
|                  |                                        # into your app folder if you
|                  |                                        # intend to use markdown
|                  |
|                  +-- demos_assets/                        # assets used by demos
|                  +-- demos_cpp/                           # lots of C++ demos
|                  +-- demos_python/                        # lots of python demos
|                  +-- imgui/                               # imgui stubs
|                  |     +-- __init__.pyi
|                  |     +-- backends.pyi
|                  |     +-- internal.pyi
|                  |     +-- py.typed
|                  +-- implot.pyi                           # implot stubs
|                  +--
|                  +-- __init__.pyi
|                  +-- hello_imgui.pyi
|                  +-- ...                                  # lots of other libs stubs
|                  +-- ...
|                  +-- ...
|                  +-- immapp/                              # immapp: immediate app
|                  |        |                               # utilities
|                  |        +--
|                  |        +-- __init__.pyi
|                  |        +--
|                  |        +-- immapp_cpp.pyi
|                  |        +--
|                  |        +-- py.typed
|                  +--  # imGui_bundle python
|                  |                                       # dynamic library
|                  +--
|                  +-- py.typed
+-- cmake/                                                 # Private cmake utilities
|         +-- add_imgui.cmake
|         +-- ...
+-- external/                                              # Root of all bound libraries
|         +-- CMakeLists.txt
|         +-- imgui/                                       # ImGui root
|         |         +-- bindings/                          # ImGui bindings
|         |         +-- imgui/                             # ImGui submodule
|         +-- ImGuizmo/
|         |         +-- bindings/                          # ImGuizmo bindings
|         |         +-- ImGuizmo/                          # ImGuizmo submodule
|         |         +-- ImGuizmoPure/                      # Manual wrappers to help
|         |                                                # bindings generation
|         |
|         +-- ... lots of other bound libraries/           # Lots of other bound libraries
|         |         +-- {lib_name}/
|         |         +-- bindings/
|         |
|         +-- _doc/
|         |
|         +-- bindings_generation/                         # Script to generate bindings
|         |         |                                      # and to facilitate external
|         |         +--                        # libraries update
|         |         +--
|         |         +--
|         |         +-- ...
|         |
|         +-- SDL/SDL/                                     # Linked library (without
|         |                                                # python bindings)
|         +-- fplus/fplus/                                 # Library without bindings
|         +-- glfw/glfw                                    # Library without bindings
+-- lg_cmake_utils/                                        # Cmake utils for bindings
|         |                                                # generation
|         +-- lg_cmake_utils.cmake
|         +-- ...
+-- pybind_native_debug/
|         +-- CMakeLists.txt
|         +--
|         +-- pybind_native_debug.cpp
|         +--
+-- src/
|         +-- imgui_bundle/                               # main cpp library: almost empty,
                                                          # but linked to all external libraries

Build and install instructions

Install for Python

Install from pypi

pip install imgui-bundle
pip install opencv-contrib-python # (1)
  1. in order to run the immvision module, install opencv-python or opencv-contrib-python

Note: under windows, you might need to install msvc redist.

Install from source:

git clone
cd imgui_bundle
git submodule update --init --recursive # (1)
pip install -v . # (2)
pip install opencv-contrib-python
  1. Since there are lots of submodules, this might take a few minutes

  2. The build process might take up to 5 minutes

Run the python demo

Simply run demo_imgui_bundle.

The source for the demos can be found inside bindings/imgui_bundle/demos_python.

Consider demo_imgui_bundle as an always available manual for Dear ImGui Bundle with lots of examples and related code source.

Install for C++

Integrate Dear ImGui Bundle in your own project in 5 minutes

The easiest way to use Dear ImGui Bundle in an external project is to use the example provided in example_integration. This folder includes everything you need to set up your own project.

Build from source

If you choose to clone this repo, follow these instructions:

git clone
cd imgui_bundle
git submodule update --init --recursive # (1)
mkdir build
cd build
make -j
  1. Since there are lots of submodules, this might take a few minutes

  2. The flag -DIMMVISION_FETCH_OPENCV=ON is optional. If set, a minimal version of OpenCV will be downloaded a compiled at this stage (this might require a few minutes)

The immvision module will only be built if OpenCV can be found. Otherwise, it will be ignored, and no error will be emitted.

If you have an existing OpenCV install, set its path via:

cmake .. -DOpenCV_DIR=/.../path/to/OpenCVConfig.cmake

Run the C++ demo

If you built ImGuiBundle from source, Simply run build/bin/demo_imgui_bundle.

The source for the demos can be found inside bindings/imgui_bundle/demos_cpp.

Consider demo_imgui_bundle as a manual with lots of examples and related code source. It is always available online

Usage instructions

Dear ImGui - Immediate GUI

Dear ImGui is an implementation of the Immediate Gui paradigm.

Consult the ImGui Manual

Dear ImGui comes with a complete demo. It demonstrates all the widgets, together with an example code on how to use them.

ImGui Manual is an easy way to consult this demo, and to see the corresponding code. The demo code is in C++, but read on for "Code advices" on how to translate from C++ to python.


An example is often worth a thousand words, the following code:


// Display a text
ImGui::Text("Counter = %i", app_state.counter);
ImGui::SameLine(); // by default ImGui starts a new line at each widget

// The following line displays a button
if (ImGui::Button("increment counter"))
    // And returns true if it was clicked: you can *immediately* handle the click
    app_state.counter += 1;

// Input a text: in C++, InputText returns a bool and modifies the text directly
bool changed = ImGui::InputText("Your name?", &;
ImGui::Text("Hello %s!",;


# Display a text
imgui.text(f"Counter = {app_state.counter}")
imgui.same_line()  # by default ImGui starts a new line at each widget

# The following line displays a button
if imgui.button("increment counter"):
    # And returns true if it was clicked: you can *immediately* handle the click
    app_state.counter += 1

# Input a text: in python, input_text returns a tuple(modified, new_value)
changed, = imgui.input_text("Your name?",
imgui.text(f"Hello {}!")

Displays this:

immediate gui example

Hello ImGui - Starter pack

Dear ImGui Bundle includes Hello ImGui, which is itself based on ImGui. "Hello ImGui" can be compared to a starter pack that enables to easily write cross-platform Gui apps for Windows, macOS, Linux, iOS, and emscripten.


See the "Hello ImGui" API doc. Also consult the doc on how to build DPI aware applications.


  • Full multiplatform support: Windows, Linux, OSX, iOS, Emscripten, Android (poorly supported). See demo video

  • Advanced layout handling

  • Power Save mode: reduce FPS when application is idle (see RunnerParams.fpsIdle)

  • DPI aware applications (widget placement, window size, font loading and scaling)

  • Theme tweaking (see demo video, and API )

  • Window geometry utilities: autosize, restore window position, full screen, etc. (see WindowGeometry)

  • Multiplatform assets embedding

  • Switch between Glfw or Sdl backend (see RunnerParams.backendType)

The usage of Hello ImGui is optional. You can also build an imgui application from scratch, in C++ or in python (see python example)
HelloImGui is fully configurable by POD (plain old data) structures. See their description

Advanced layout and theming with Hello ImGui:

See the demo named "demo_docking", which demonstrates:

  • How to handle complex layouts: you can define several layouts and switch between them: each layout which will remember the user modifications and the list of opened windows

  • How to use theming

  • How to store you own user settings in the app ini file

  • How to add a status bar and a log window

  • How to reduce the FPS when idling (to reduce CPU usage)


ImmApp - Immediate App

ImGui Bundle includes a library named ImmApp (which stands for Immediate App). ImmApp is a thin extension of HelloImGui that enables to easily initialize the ImGuiBundle addons that require additional setup at startup

How to start an application with addons

Click to see an example application with addons

Some libraries included by ImGui Bundle require an initialization at startup. ImmApp makes this easy via AddOnParams.

The example program below demonstrates how to run an application which will use implot (which requires a context to be created at startup), and imgui_md (which requires additional fonts to be loaded at startup).


#include "immapp/immapp.h"
#include "imgui_md_wrapper/imgui_md_wrapper.h"
#include "implot/implot.h"
#include "demo_utils/api_demos.h"
#include <vector>
#include <cmath>

int main(int, char**)
    // This call is specific to the ImGui Bundle interactive manual. In a standard application, you could write:
    //         HelloImGui::SetAssetsFolder("my_assets"); // (By default, HelloImGui will search inside "assets")

    constexpr double pi = 3.1415926535897932384626433;
    std::vector<double> x, y1, y2;
    for (double _x = 0; _x < 4 * pi; _x += 0.01)

    auto gui = [x,y1,y2]()
        ImGuiMd::Render("# This is the plot of _cosinus_ and *sinus*");  // Markdown
        if (ImPlot::BeginPlot("Plot"))
            ImPlot::PlotLine("y1",,, x.size());
            ImPlot::PlotLine("y2",,, x.size());

    HelloImGui::SimpleRunnerParams runnerParams { .guiFunction = gui, .windowSize = {600, 400} };
    ImmApp::AddOnsParams addons { .withImplot = true, .withMarkdown = true };
    ImmApp::Run(runnerParams, addons);

    return 0;


import numpy as np
from imgui_bundle import implot, imgui_md, immapp
from imgui_bundle.demos_python import demo_utils

def main():
    # This call is specific to the ImGui Bundle interactive manual. In a standard application, you could write:
    #         hello_imgui.set_assets_folder("my_assets"); # (By default, HelloImGui will search inside "assets")

    x = np.arange(0, np.pi * 4, 0.01)
    y1 = np.cos(x)
    y2 = np.sin(x)

    def gui():
        imgui_md.render("# This is the plot of _cosinus_ and *sinus*")  # Markdown
        if implot.begin_plot("Plot"):
            implot.plot_line("y1", x, y1)
            implot.plot_line("y2", x, y2)
            implot.end_plot(), with_implot=True, with_markdown=True, window_size=(600, 400))

if __name__ == "__main__":

Using Dear ImGui Bundle with jupyter notebook

ImmApp adds support for integration inside jupyter notebook: the application will be run in an external window, and a screenshot will be placed on the notebook after execution.

This requires a window server, and will not run on google collab.

Below is a screenshot, that you can test by running jupyter notebook inside bindings/imgui_bundle/demos_python/notebooks

immapp notebook example

C++ / Python porting advices

General advices

ImGui is a C++ library that was ported to Python. In order to work with it, you will often refer to its manual, which shows example code in C++.

In order to translate from C++ to Python:

  1. Change the function names and parameters' names from CamelCase to snake_case

  2. Change the way the output are handled.

    1. in C++ ImGui::RadioButton modifies its second parameter (which is passed by address) and returns true if the user clicked the radio button.

    2. In python, the (possibly modified) value is transmitted via the return: imgui.radio_button returns a Tuple[bool, str] which contains (user_clicked, new_value).

  3. if porting some code that uses static variables, use the @immapp.static decorator. In this case, this decorator simply adds a variable value at the function scope. It is preserved between calls. Normally, this variable should be accessed via demo_radio_button.value, however the first line of the function adds a synonym named static for more clarity. Do not overuse them! Static variable suffer from almost the same shortcomings as global variables, so you should prefer to modify an application state.



void DemoRadioButton()
    static int value = 0;
    ImGui::RadioButton("radio a", &value, 0); ImGui::SameLine();
    ImGui::RadioButton("radio b", &value, 1); ImGui::SameLine();
    ImGui::RadioButton("radio c", &value, 2);


def demo_radio_button():
    static = demo_radio_button
    clicked, static.value = imgui.radio_button("radio a", static.value, 0)
    clicked, static.value = imgui.radio_button("radio b", static.value, 1)
    clicked, static.value = imgui.radio_button("radio c", static.value, 2)

Enums and TextInput

In the example below, two differences are important:

InputText functions:

imgui.input_text (Python) is equivalent to ImGui::InputText (C++)

  • In C++, it uses two parameters for the text: the text pointer, and its length.

  • In Python, you can simply pass a string, and get back its modified value in the returned tuple.

Enums handling:

  • ImGuiInputTextFlags_ (C++) corresponds to imgui.InputTextFlags_ (python) and it is an enum (note the trailing underscore).

  • ImGuiInputTextFlags (C++) corresponds to imgui.InputTextFlags (python) and it is an int (note: no trailing underscore)

You will find many similar enums.

The dichotomy between int and enums, enables you to write flags that are a combinations of values from the enum (see example below).



void DemoInputTextUpperCase()
    static char text[64] = "";
    ImGuiInputTextFlags flags = (
        | ImGuiInputTextFlags_CharsNoBlank
    /*bool changed = */ ImGui::InputText("Upper case, no spaces", text, 64, flags);


def demo_input_text_decimal() -> None:
    static = demo_input_text_decimal
    flags:imgui.InputTextFlags = (
          | imgui.InputTextFlags_.chars_no_blank.value
    changed, static.text = imgui.input_text("Upper case, no spaces", static.text, flags)

Note: in C++, by using imgui_stdlib.h, it is also possible to write:

#include "imgui/misc/cpp/imgui_stdlib.h"

void DemoInputTextUpperCase_StdString()
    static std::string text;
    ImGuiInputTextFlags flags = (
        | ImGuiInputTextFlags_CharsNoBlank
    /*bool changed = */ ImGui::InputText("Upper case, no spaces", &text, flags);

Advanced glfw callbacks

When using the glfw backend, you can set advanced callbacks on all glfw events.

Below is an example that triggers a callback whenever the window size is changed:

import imgui_bundle
import glfw   # always import glfw *after* imgui_bundle!!!

# define a callback
def my_window_size_callback(window: glfw._GLFWwindow, w: int, h: int):
    print(f"Window size changed to {w}x{h}")

# Get the glfw window used by hello imgui
window = imgui_bundle.glfw_utils.glfw_window_hello_imgui()
glfw.set_window_size_callback(window, my_window_size_callback)
It is important to import glfw after imgui_bundle, since - upon import - imgui_bundle informs glfw that it shall use its own version of the glfw dynamic library.

Debug native C++ in python scripts

ImGui Bundle provides tooling to help you debug the C++ side, when you encounter a bug that is difficult to diagnose from Python.

It can be used in two steps:

  1. Edit the file pybind_native_debug/ Change its content so that it runs the python code you would like to debug. Make sure it works when you run it as a python script.

  2. Now, debug the C++ project pybind_native_debug_bundle which is defined in the directory pybind_native_debug/. This will run your python code from C++, and you can debug the C++ side (place breakpoints, watch variables, etc).

Example: this issue on macOS was solved thanks to this.

Closing words

Who is this project for

As mentioned in the intro,

Dear ImGui Bundle is a bundle for Dear ImGui, including various powerful libraries from its ecosystem. It enables to easily create ImGui applications in C++ and Python, under Windows, macOS, and Linux. It is aimed at application developers, researchers, and beginner developers who want to quickly get started.

Dear ImGui Bundle aims to make applications prototyping fast and easy, in a multiplatform / multi-tooling context. The intent is to reduce the time between an idea and a first GUI prototype down to almost zero.

It is well adapted for

  • developers and researchers who want to switch easily between and research and development environment by facilitating the port of research artifacts

  • beginners and developers who want to quickly develop an application without learning a GUI framework

Who is this project not for

You should prefer a more complete framework (such as Qt for example) if your intent is to build a fully fledged application, with support for internationalization, advanced styling, etc.

Also, the library makes no guarantee of ABI stability, and its API is opened to slight adaptations and breaking changes if they are found to make the overall usage better and/or safer.


Dear ImGui Bundle would not be possible without the work of the authors of "Dear ImGui", and especially Omar Cornut.

It also includes a lot of other projects, and I’d like to thank their authors for their awesome work!

A particular mention for Evan Pezent (author of ImPlot), Cédric Guillemet (author of ImGuizmo), Balázs Jákó (author of ImGuiColorTextEdit), and Michał Cichoń (author of imgui-node-editor), and Dmitry Mekhontsev (author of imgui-md), Andy Borrel (author of imgui-tex-inspect, another image debugging tool, which I discovered long after having developed immvision).

This doc was built using Asciidoc.

Immvision was inspired by The Image Debugger, by Bill Baxter.


The MIT License (MIT)

Copyright (c) 2021-2023 Pascal Thomet

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions:

The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software.



pyimgui provides battle-tested comprehensive python bindings for ImGui. I worked with this project a lot, and contributed a bit to it. In the end, I had to develop a separate project, in order to be able to add auto-generated and auto-documented python modules.

Dear PyGui (repository) provides python bindings for ImGui with a lot of addons, and a more pythonesque API, which makes it perhaps more suited for Python only projects.

About the author

Dear ImGui Bundle is developed by Pascal Thomet. I am reachable on my Github page. I sometimes blog. There is a playlist related to ImGui Bundle on YouTube.

I have a past in computer vision, and a lot of experience in the trenches between development and research teams; and I found ImGui to be a nice way to reduce the delay between a research prototype and its use in production code.

I also have an inclination for self documenting code, and the doc you are reading was a way to explore new ways to document projects.

How is Dear ImGui Bundle developed

The development of the initial version of Dear ImGui Bundle took about one year at full time.

The bindings are auto-generated thanks to an advanced parser, so that they are easy to keep up to date. I’ll give more information about the bindings generator a bit later in 2023.

Please be tolerant if you find issues! Dear ImGui Bundle is developed for free, under a very permissive license, by one main author (and most of its API comes from external libraries).

If you need consulting about this library or about the bindings generator in the context of a commercial project, please contact me by email.

Contributions are welcome!


Three of my past projects gave me the idea to develop this library.

  • ImGui Manual, an interactive manual for Dear ImGui, which I developed in June 2020

  • implot demo which I developed in 2020.

  • imgui_datascience, a python package I developed in 2018 for image analysis and debugging. Its successor is immvision.

Developments for Dear ImGui Bundle and its related automatic binding generator began in january 2022.
